Stainless Steel Pinch Clamps

Item #: CG-150
Quantity:
$18.50

Normal Availability: 1-3 business days

Product Description

These stainless steel pinch clamps are ideal for securing O-ring (for example, item # CG-124) and spherical joints (item # CG-120). Items CG-150-01 and CG-150-03 are supplied WITHOUT a screw type locking device. All other sizes have the screw type locking device shown in the picture.

Item # Clamp size O-ring joint size, ID Spherical ball joint size
CG-150-01 (no lock)
CG-150-02
12 5 mm (#110 O-ring) 12 mm e.g. 12/1, 12/2, 12/3 or 12/5
CG-150-03 (no lock)
CG-150-04
18 7 or 9 mm (#111 or #112 O-ring) 18 mm e.g. 18/7 or 18/9
CG-150-05 28 12 or 15 mm (#116 O-ring) 28 mm e.g. 28/12 or 28/18
CG-150-06 35 20 or 25 mm (#214 or #217 O-ring) 35 mm e.g. 35/20 or 35/25
CG-150-07 40   40 mm e.g. 40/25
CG-15-08 50 30 mm (#223 O-ring) 50 mm e.g. 50/30
CG-150-09 65   65 mm e.g. 65/40
CG-150-21 75 75 mm (#341 O-ring) 75 mm e.g. 75/50



A #102 clamp is available by special order only.

For a discussion of joint sizing, see the Joints entry in the Glassware Gallery.

Other Details

Manufactured in: USA
