Ansul Red Line I-20-G-1 Cartridge Extinguishers (All Models), BC, 20 lb

Item #: 09726

Availability: 1-2 weeks

Product Description

Ansul Red Line dry chemical extinguishers utilize a gas cartridge system so they are field-refillable (with proper training) and inspections can be made on every moving part. This extinguisher is used in industries where the occurence or possibility of fire is high.  These Model 20 units are ideal for remote locations where smaller fires occur and on-the-spot-recharging is necessary. Typical applications include dip tanks, storage drums, oil pumping stations, turbines, compressors, quench tanks and other large industrial applications

This page lists all of the Red Line BC 20 lb series extinguishers with the Plus Fifty-C extinguishing agent. The following configurations are available in addition to the standard I-20-G-1 model:

  • Ring Pin - This extinguisher features a ring pin which, when inserted in the cartridge receiver, provides secondary protection against accidental actuation of the unit when the hose is not in place. The operating instruction nameplate notes the removal of the ring pin before actuation - make sure you users are trained in this procedure!
  • Corrosion Resistant - All steel parts of this corrosion-resistant model are treated with a zinc-rich primer before application of the oven-cured powder paint. The cartridge receiver body is painted with epoxy paint and the hose couplings, fill cap, carrying handle, nozzle body, nozzle lever, nozzle tip and receiver push lock are black anodized for corrosion resistance.
  • Low Temperature - This special low-temperature model is equipped with a nitrogen cartridge and a cartridge receiver which is approved for operation in environments with temperatures as low as -65 °F (-54 °C).

See the table below for extinguisher model numbers, Ansul part numbers, and specifications. Replacement gas cartridges (item # 09758) and dry chemical refill agents are also available. The Safety Data Sheet (SDS) for Plus-Fifty C is available for download.

For 20 lb Red Line BC Purple-K models (I-K-20-G-1) see item # 09724. For 20 lb Red Line ABC extinguishers filled with Foray extinguishing agent (model series I-A-20-G-1) see item # 09719

Ansul's specification sheet for handheld 5, 10, 20, and 30 lb Red Line models is available for download. Red Line handheld features include:

  • 3 piece, welded steel dry chemical tank.
  • Forged aluminum handle designed for easy carrying.
  • Cast aluminum cartridge receiver with stainless steel insert.
  • Large 3-inch opening for fast and easy recharging.
  • Manufacturer's limited 5 year warranty.
  • Bracket is not included - order separately.


Type Standard Ring Pin Corrosion-Resistant Low Temperature
Ansul Model # I-20-G-1 RP-I-20-G-1 CR-I-20-G-1 LT-I-20-G-1
Ansul Part # 434537 434538 434542 434543
Agent 20 lb (9.1 kg) Plus-Fifty C
UL/ULC Rating 60-B:C
US Coast Guard Classification Type B:C, Size III
Discharge Time 22 seconds
Maximum Effective Range 24 ft (7.3 m)
Nozzle Stream Expanding
Approvals UL, FM, USCG (with bracket)
Charged Weight (with agent) 38 lb (17.2 kg)
Height 20.5" (52.1cm)
Width 10.4" (26.4 cm)
Depth 7.0" (17.8 cm)
Shell O.D. 6.0" (15 cm)
Hose I.D. 0.5" (1.3 cm)
Hose Length 31.6" (80.3 cm)
Vehicle Brackets (see item # 09772)
Fire Suppression Capability
(Novice Operator)
40 sq ft (7.4 sq m)
Fire Suppression Capability
(Experienced Operator)
100 sq ft (9.3 sq m)

Other Details

Manufactured in: USA
