L7834 Pure Water Faucet, Polypropylene-Lined, Panel Mounted

The WaterSaver Faucet Co.'s L7834 Pure Water Faucet is a panel-mounted unit for distilled, deionized or reverse osmosis system water. The faucet has exterior brass casing and interior lining of inert polypropylene so that purified water comes in contact only with inert polypropylene.

The valve body is made of forged brass with a polished chrome-plated finish. The valve unit consists of a diaphragm-type valve and features a brass valve stem and bonnet with an elastomer diaphragm. The valve has manual on/off control.

This item features a black white nylon knurled handle with a color-coded index disc marked DI. The riser is 6" and made of brass. The inlet is a 3/8" IPS male shank with a 3/8" OD tube connection. A 3/8" OD compression adapter is included with the inlet. The outlet features a six-serration plastic hose end. Each unit is fully assembled and factory tested prior to shipment.

Installation guidelines are available on-line and a specification drawing is available as a PDF file. Available options for this unit include:

• L7834SC - Has a toggle-style lever handle and self-closing control.

• L7834MSC - Has a toggle-style lever handle and combination manual / self-closing control.

A polyvinylidene fluoride (PVDF) lining rather than polypropylene (suffix -PVDF) is available on a special order basis only. Please contact us for pricing and availability.

The L7833 is similar, but is deck-mounted.  Additional pure water fixtures can be special ordered.

FOR LABORATORY USE ONLY
